Wren Kitchens INFINITY Base Unit Fittings Manual page 6

Sliding the unit into place
When sliding the unit into place do not tilt as
this can damage the legs.
Place the unit against the wall and align it
with the wall markings that will have been
drawn during the room preparation stage.
Use a spirit level to ensure the unit is
level from front to back, left to right, and
diagonally. Adjust the legs if required.
The leg height can be adjusted by turning the
foot of the leg clockwise or anti-clockwise.
The corner post will be divided into two pieces, Z and Y. The sizes of the pieces will vary based on
Correct dimensions will be obtained through the following steps.
Positioning the adjacent base unit
To determine the corner post measurements,
position the adjacent base unit in line with
wall markings.
Use a spirit level to level the unit front to
back, left to right, and diagonally, and adjust
the legs if necessary.
the room dimensions and the kitchen plan.
