Position the blanking panel with its white side facing the unit
Fixing the blanking panel
Position 7x15mm screws 9mm from the
edges of the blanking panel to secure it into
the unit end panel, top rail, and bottom fixed
shelf, ensuring the screws are evenly spaced.
No screws or wall plugs are provided for attaching the unit to the wall.
Before drilling into the wall you MUST check for any hidden services or pipework within the walls.
Drilling the pilot holes
Drill 2 pilot holes through the rear top rail and
be sure to lightly mark the wall to indicate
the location of the wall fixing. The size of the
holes will be determined by the size of wall
fixing required.
For guidance on the appropriate wall fixing
for each wall type, please consult the "Room
Preparation Guide."
Once complete lift and move the unit away
from the wall.
Using the pilot holes, drill a hole to suit the
fixings. Place the wall fixings within the holes.
Lift and reposition the unit, ensuring it is level
and inline with the wall markings.
This is due to variations in wall construction.
