Drilling holes into Packer Z1
Lightly mark the center of Packer Z1 and drill
four holes along the line, ensuring the screws
are equally spaced.
Mark the top and bottom of Packer Z1 30mm
in from the sides.
Drilling the pilot holes for the packer fixing
Packer Z1 should be positioned closely to the
centre post and in line with the front edge of
the unit. Position on the opposite side to the
hinge plates.
On the unit's front rail and base panel,
transfer the 30mm markings from the
packer's top.
Remove the packer and drill where the
markings are on the unit 9mm from the
edge.
