Wren Kitchens INFINITY Base Unit Fittings Manual page 5

Attaching the packer to the unit
Place the packer back into position.
Screw through the unit using 4x30mm
screws, 2 in the top and 2 in the bottom using
the pilot holes to attach the packer piece.
Lifting the unit into place
When lifting the unit into place do not tilt as
this can damage the legs.
Notching out the end panels (when
required)
In order to allow for any horizontal pipework
running behind the unit, some units will
require the back of unit's side to be notched
out.
Create a notch for the horizontal pipes at the
back of the end panels using a jigsaw.
Page 5
