Wren Kitchens INFINITY Base Unit Fittings Manual page 11

Inserting the space plugs
Position the space plugs between the wall
and the back of the unit, where the holes are
located.
Unwind until the space plugs touch both the
back panel of the unit and the wall.
Insert the screws into the drilled holes and
tighten to the wall.
Securing the adjacent unit to the corner
post
Place the adjacent base unit next to the
corner post in line with the markings on the
wall. Both of the runs must be straight and
the units must be level.
Screw into the side of the unit using 2x30mm
screws, where possible, these should be
positioned in front of the hinge plates.
Screw 9mm in from the edge of the unit, in
the centre of the hinge plates (if possible).
This will ensure the unit is attached to Packer
Y1.
Place a cover cap on the heads to conceal the
visible screw heads.
Page 11
