5 Operation
5.10 Monitor setup
Setup adjust cell constant
After replacing the flow cell, the cell constant has to be set. (The cell constant is shown
on the packaging).
Step
1
2
3
4
Setup show conductivity
Step
1
2
3
76
Action
Select sub menu Setup Cond and press OK.
Select sub menu Setup Adjust Cell Const and press
OK. The current cell constant is shown.
A warning message is shown until confirmed by
pressing OK.
The current cell constant value is displayed as default.
Enter the new cell constant as read from the packaging
and press OK. The range is 0.1–300.0 cm
When entering the cell constant from UNICORN, select
System Control:System:Calibrate and select
Cond_Cell.
Action
Select sub menu Setup Cond and press OK.
Select sub menu Setup Show Cond and press OK. The
current status for showing conductivity is displayed. If
on is shown, current conductivity is displayed in main
menus 1 and 2. If off is shown, no conductivity is dis-
played in the main menus.
Change the setting if desired and press OK.
