Setup pH temperature
compensation
The relationship between pH and the output signal from the pH electrode is temperature
dependent. For accurate measurements during temperature changes, the pH measure-
ment can be temperature compensated. In normal applications, when the temperatures
of the buffers and calibration buffers are identical, temperature compensation is not
necessary.
When using temperature compensation, it is important that the temperature of the pH
electrode is the same as that of the conductivity flow cell since that is where the temper-
ature is measured.
Step
1
2
3
Monitor UPC-900 Operating Instructions 29-0567-16 AB
Action
Select sub menu Setup pH and press OK.
Select sub menu Setup pH Temp Comp and press OK.
The current status for showing pH is displayed. If on is
shown, Tc is displayed in main menus 1 and 2. If off is
shown (default), Tc is not displayed in the main menus.
Change the setting if desired and press OK.
5 Operation
5.10 Monitor setup
Display
Setup
Temp Cond pH UV
Setup
Setup
Setup pH Temp Comp
Temp Cond pH UV
Temp Cond pH UV
(off)
Setup pH Temp Comp
Setup pH Temp Comp
(off)
(off)
Setup pH Temp Comp
(off) on off
Setup pH Temp Comp
Setup pH Temp Comp
(off) on off
(off) on off
Setup
Temp Cond pH UV
Setup
Setup
Setup Show pH
Temp Cond pH UV
Temp Cond pH UV
(on)
Setup Show pH
Setup Show pH
(on)
(on)
Setup Show pH
(on) on off
Setup Show pH
Setup Show pH
(on) on off
(on) on off
Setup
Temp Cond pH UV
Setup
Setup
Set Averaging
Temp Cond pH UV
Temp Cond pH UV
(1.3S) 1.3
Set Averaging
Set Averaging
(1.3S) 1.3
(1.3S) 1.3
Set Averaging
(1.3S) 0.64
Set Averaging
Set Averaging
(1.3S) 0.64
(1.3S) 0.64
