Setup adjust temperature
Calibration of the temperature sensor in the conductivity flow cell is only necessary if
the monitor is used in high accuracy measurement or if the conductivity flow cell is re-
placed.
Step
1
2
3
4
5
6
Monitor UPC-900 Operating Instructions 29-0567-16 AB
Action
Place the flow cell together with a precision thermome-
ter inside a box or empty beaker to make sure that they
are not exposed to draught. Leave them for 15 minutes
to let the temperature stabilize.
Read the temperature on the thermometer.
Select sub menu Setup Temp and press OK.
Select sub menu Setup Adjust Temp and press OK. The
current temperature is shown.
A warning message is shown until confirmed by
pressing OK.
The current adjustment value is displayed as default.
Enter the temperature shown on the thermometer and
press OK.
Date of Maintenance:
UPC-900
Buzzer Test
?
V1.00
Date of Maintenance:
Buzzer Test
?
5 Operation
5.10 Monitor setup
Buzzer Test
Setup
Temp Cond pH UV
Setup
Temp Cond pH UV
Display
Setup
Temp Cond pH UV
Setup
Temp Cond pH UV
Setup
Setup Show Temp
Temp Cond pH UV
(on)
Setup
Setup Adjust Temp
Setup Show Temp
Temp Cond pH UV
(22.3°C)
(on) on off
Setup Setup Adjust Temp
Warning! This will
Setup
(22.3°C) Temp Cond pH UV
change temp calib
Temp Cond pH UV
Warning! This will Setup Adjust Temp
Setup Adjust Temp
Setup Cond Temp Comp
change temp calib (22.3°C)
(22.3°C) 22.3
(0.0%)
Setup Adjust Temp
Warning! This will
Setup Cond Temp Comp
(22.3°C) 22.3
change temp calib
(0.0%) 0.0
Setup Adjust Temp
Setup
(22.3°C) 22.3
Temp Cond pH UV
Setup Cond Ref Temp
(25.0°C)
Setup Cond Ref Temp
(25.0%) 25.0
