4 Installation
4.6 Communication and power supply
Connect to a communication link
The monitor can be controlled from the front dial and display or controlled from a PC
running UNICORN™ version 3.0 or higher via UniNet 1 cables.
Connect two UniNet 1 cables to the UniNet 1 connectors. The module can be connected
in series anywhere between the PC and a termination plug. The UniNet 1 link can connect,
in series, the PC with Pump P-920, Monitor UPC-900 and the Frac-920. The termination
plug is connected to the last module in the chain.
Connect to supply voltage
Step
1
2
Note:
44
NOTICE
Any computer used with the equipment must comply with IEC
60950 and be installed and used according to the manufacturer's
instructions.
WARNING
Protective ground. The product must always be connected to a
grounded power outlet.
Action
Make sure the Power switch is in the OFF-position (0).
Connect the supplied mains cable between the module and a grounded
mains socket. Any voltage from 100 to 240 VAC, 50 to 60 Hz can be used.
The module contains no user-replaceable fuse.
