1 Introduction

ADLINK IMB-M47 ATX is an industrial motherboard supporting 12/13th Generation Intel® Core™ i9/i7/i5/i3 desktop
processors, an Intel® Q670 Chipset, and 7 PCIe expansion slots to provide a cost-competitive embedded
computing solution. It includes high-speed data transfer interfaces such as PCIe 5.0, USB 3.2 Gen2, and SATA 6
Gb/s (SATA III), and dual-channel DDR5 3600/4000/4800 MHz RAM for industrial automation applications. With
industrial-grade I/O port design, the IMB-M47 offers a significant competitive advantage for embedded computing
applications in terms of device compatibility, durable connectivity, and extreme environment readiness.
1.1

Packing List

IMB-M47 ATX motherboard
Rear I/O shield
M.2 screw kit
1.2

Optional Accessories

CPU cooler for 65W CPU (Part Number: 32-20976-0000-A0)
CPU cooler for 125W CPU (available by request only)
2-port USB 2.0 cable with bracket (Part Number: 30-25010-3010)
2-port USB 3.0 cable with bracket (Part Number: 30-25046-0100)
1-port LPT cable with bracket (Part Number: 30-25019-2000)
2-port COM cable with bracket (Part Number: 30-25116-0000-A0)
