Opening the Active Directory Users and Computers Snap-In

To open the Active Directory Users and Computers snap-in, perform the following steps:
1 If you are on the domain controller, click Start Admin Tools
Computers. If you are not on the domain controller, you must have the appropriate Microsoft
Administrator Pack installed on your local system. To install this Administrator Pack, click
Start Run, type MMC and press <Enter>.
This opens the Microsoft Management Console (MMC).
2 Click File (or Console on systems running Windows 2000) in the Console 1 window.
3 Click Add/Remove Snap-in.
4 Select the Active Directory Users and Computers snap-in and click Add.
5 Click Close and click OK.

Adding DRAC 4 Users and Privileges to Active Directory

The Dell-extended Active Directory Users and Computers snap-in allows you to add DRAC 4
users and privileges by creating RAC, Association, and Privilege objects. To add each type of
object, perform the steps in each subsections.

Creating a RAC Device Object

1 In the MMC Console Root window, right-click a container.
2 Select New
Dell RAC Object.
This opens the New Object window.
3 Type a name for the new object. This name must match the DRAC 4 Name that you will type
in step 4 of "Configuring the DRAC 4."
4 Select RAC Device Object.
5 Click OK.

Creating a Privilege Object

Privilege Objects must be created in the same domain as the Association Object to which it
is associated.
1 In the Console Root (MMC) window, right-click a container.
2 Select New
Dell RAC Object.
This opens the New Object window.
3 Type a name for the new object.
Active Directory Users and
Using the DRAC 4 With Microsoft
®
95
Active Directory
