Configuring and Using Virtual Media

Overview

The Virtual Media feature provides the managed system with a virtual floppy diskette drive and
a virtual CD drive, which can use standard media from anywhere on the network. (Figure 7-1
shows the overall architecture of virtual media.) With this feature, administrators can remotely
boot their managed systems, install applications, update drivers, or even install new operating
systems remotely from the virtual CD/floppy diskette drives.
Figure 7-1. Overall Architecture of Virtual Media
Managed System
DRAC 4
Virtual CD
Virtual Floppy
Network
Configuring and Using Virtual Media
Management Station
Remote CD
Remote Floppy
