4 Click Next to run the Dell Schema Extender.
5 Click Finish.
The schema is extended. To verify the schema extension, use the Microsoft Management
Console (MMC), the Active Directory Schema snap-in to verify the existence of the following
classes (listed in Table 5-1, Table 5-2, Table 5-3, Table 5-4, Table 5-5, and Table 5-6) and
attributes (listed in Table 5-7). See your Microsoft documentation for more information on
how to enable and use the Active Directory Schema snap-in the MMC.

Table 5-1. Class Definitions for Classes Added to the Active Directory Schema

Class Name
dellRacDevice
dellAssociationObject
dellRAC4Privileges
dellPrivileges
dellProduct

Table 5-2. dellRacDevice Class

OID
Description
Class Type
SuperClasses
Attributes

Table 5-3. dellAssociationObject Class

OID
Description
Class Type
SuperClasses
Attributes
Assigned Object Identification Number (OID)
1.2.840.113556.1.8000.1280.1.1.1.1
1.2.840.113556.1.8000.1280.1.1.1.2
1.2.840.113556.1.8000.1280.1.1.1.3
1.2.840.113556.1.8000.1280.1.1.1.4
1.2.840.113556.1.8000.1280.1.1.1.5
1.2.840.113556.1.8000.1280.1.1.1.1
This class represents the Dell RAC device. The RAC device must be
configured as dellRacDevice in Active Directory. This configuration enables
the DRAC 4 to send Lightweight Directory Access Protocol (LDAP) queries
to Active Directory.
Structural Class
dellProduct
dellSchemaVersion
dellRacType
1.2.840.113556.1.8000.1280.1.1.1.2
This class represents the Dell Association Object. The Association Object
provides the connection between the users and the devices.
Structural Class
Group
dellProductMembers
dellPrivilegeMember
Using the DRAC 4 With Microsoft
®
91
Active Directory
