    7. LW3 Programmers' Reference
7.6.4. Muting the Video Port
Command and Response
ç
SET·/V1/MEDIA/VIDEO/XP/<port>.Mute=<muted_state>
pw·/V1/MEDIA/VIDEO/XP/<port>.Mute=<muted_state>
æ
Parameters
Parameter Parameter description
<muted_state> Muted state
Example
ç SET /V1/MEDIA/VIDEO/XP/I2.Mute=false
æ pw /V1/MEDIA/VIDEO/XP/I2.Mute=false
7.6.5. Setting the Autoselect Policy
Command and Response
SET·/V1/MEDIA/VIDEO/AUTOSELECT/<out>.Policy=<autoselect_mode>
ç
pw·/V1/MEDIA/VIDEO/AUTOSELECT/<out>.Policy=<autoselect_mode>
æ
Parameters
Parameter Parameter description
<autoselect_mode> The autoselect policy
Example
ç SET /V1/MEDIA/VIDEO/AUTOSELECT/O2.Policy=First detect
æ pw /V1/MEDIA/VIDEO/AUTOSELECT/O2.Policy=First detect
Values Value description
true The port is locked.
false The port is unlocked.
Values Value description
Off The autoselect function is disabled.
It is always the last attached input that is
Last Detect
automatically switched to the output.
The first active video input is selected.
First Detect
Applied firmware package: v2.9.0b6 | LDC software: v2.7.6b4
MMX2 series – User's Manual
7.6.6. Changing the Autoselect Included Input Ports
Command and Response
SET·/V1/MEDIA/VIDEO/AUTOSELECT/<out>/<in>.Included=<state>
ç
pw·/V1/MEDIA/VIDEO/AUTOSELECT/<out>/<in>.Included=<state>
æ
Parameters
Parameter Parameter description
<state> The chosen input is ignored in the
autoselect process or not.
Example
ç SET /V1/MEDIA/VIDEO/AUTOSELECT/O2/I1.Included=false
æ pw /V1/MEDIA/VIDEO/AUTOSELECT/O2/I1.Included=false
7.6.7. Changing the Input Port Priority
Command and Response
SET·/V1/MEDIA/VIDEO/AUTOSELECT/<out>/<in>.Priority=<prio_num>
ç
pw·/V1/MEDIA/VIDEO/AUTOSELECT/<out>/<in>.Priority=<prio_num>
æ
Parameters
The <prio> parameter means the priority number from 1 to 100, equal numbers are allowed. Inputs can have
different priorities in relation to two or more outputs. Therefore, the output port number is part of the node
path of input port priorities.
Example
ç SET /V1/MEDIA/VIDEO/AUTOSELECT/O2/I2.Priority=51
æ pw /V1/MEDIA/VIDEO/AUTOSELECT/O2/I2.Priority=51
7.6.8. Querying the Connected Source
Command and Response
ç GET·/V1/MEDIA/VIDEO/XP/<out>.ConnectedSource
æ
pw·/V1/MEDIA/VIDEO/XP/<out>.ConnectedSource=<in>
Example
ç GET /V1/MEDIA/VIDEO/XP/O3.ConnectedSource
æ pw /V1/MEDIA/VIDEO/XP/O3.ConnectedSource=I2
Values Value description
true The port is included in autoselect.
false The autoselect function ignores that port.
