    7. LW3 Programmers' Reference
7.6.14. OutputSignalType
Command and Response
#signaltype
SET·/V1/MEDIA/VIDEO/<out>.OutputSignalType=<signal_type>
ç
æ pw·/V1/MEDIA/VIDEO/<out>.OutputSignalType=<signal_type>
Parameters
Parameter Parameter description Values
<signal_type> Signal type setting
Example
ç SET /V1/MEDIA/VIDEO/O1.OutputSignalType=Auto
æ pw /V1/MEDIA/VIDEO/O1.OutputSignalType=Auto
7.6.15. EmbeddedAudioPresent
ç GET·/V1/MEDIA/VIDEO/<port>.EmbeddedAudioPresent
æ pr·/V1/MEDIA/VIDEO/<port>.EmbeddedAudioPresent=<embedded_state>
Parameters
Parameter Parameter description Values
<embedded_state> It shows if the video
contains audio or not.
Example
ç GET /V1/MEDIA/VIDEO/I2.EmbeddedAudioPresent
æ pr /V1/MEDIA/VIDEO/I2.EmbeddedAudioPresent=false
7.6.16. EmbeddedAudioMute
SET·/V1/MEDIA/VIDEO/<port>.EmbeddedAudioMute=<mute_state>
ç
æ pw·/V1/MEDIA/VIDEO/<port>.EmbeddedAudioMute=<mute_state>
Parameters
Parameter Parameter description Values
<mute_state> It shows if the
embedded audio is
muted or not.
Example
ç SET /V1/MEDIA/VIDEO/O1.EmbeddedAudioMute=false
æ pw /V1/MEDIA/VIDEO/O1.EmbeddedAudioMute=false
Value description
Auto The outgoing signal type is HDMI.
The outgoing signal type is DVI.
DVI
Value description
true There is embedded audio in the video signal.
false There is no embedded audio in the video signal.
Value description
The embedded audio is muted.
true
The embedded audio is unmuted.
false
Applied firmware package: v2.9.0b6 | LDC software: v2.7.6b4
MMX2 series – User's Manual
7.6.17. Output5VMode
The 5V power towards the sink can be enabled or disabled as follows:
Command and Response
SET·/V1/MEDIA/VIDEO/<out>.Output5VMode=<5V_pwr>
ç
pw·/V1/MEDIA/VIDEO/<out>.Output5VMode=<5V_pwr>
æ
Parameters
Parameter description
Parameter
<5V_pwr> 5V power towards the sink
Example
ç SET /V1/MEDIA/VIDEO/O1.Output5VMode=On
æ pw /V1/MEDIA/VIDEO/O1.Output5VMode=On
7.6.18. HDCP Capability (Output Port)
HDCP capability of the connected sink device can be queried at each output port. See more information in
the HDCP Management section.
Command and Response
#hdcp
GET·/V1/MEDIA/VIDEO/<out>/HDCP/SinkMaxHdcpVersion=<hdcp_ver>
ç
pr·/V1/MEDIA/VIDEO/<out>/HDCP/SinkMaxHdcpVersion=<hdcp_ver>
æ
Parameters
Parameter Parameter description
<hdcp_ver> The HDCP capabality is
reported from the sink.
Example
ç GET /V1/MEDIA/VIDEO/O1/HDCP/SinkMaxHdcpVersion=HDCP 1.4
æ pr /V1/MEDIA/VIDEO/O1/HDCP/SinkMaxHdcpVersion=HDCP 1.4
Value Value description
Enable 5V power on HDMI port
On
Disable 5V power on HDMI port
Off
Values Value description
Sink is not connected or the HDCP-capability cannot
N/A
be determined.
The connected sink is non-HDCP compliant.
None
The connected sink supports HDCP 1.4 capability.
HDCP 1.4
The connected sink supports HDCP 2.2 capability.
HDCP 2.2
