    7. Lightware REST API Reference
Setting Output Signal Type
request-line: POST·http://<ip>/api/V1/MEDIA/VIDEO/<out>/OutputSignalType·HTTP/1.1
ɯ
body: <signal_type>
ɯ
Turning on Output 5V
request-line: POST·http://<ip>/api/V1/MEDIA/VIDEO/<out>/Output5VMode·HTTP/1.1
ɯ
<5V_pwr>
ɯ body:
CEC Command Sending
Simple CEC Code Sending
request-line: POST·http://<ip>/api/V1/MEDIA/VIDEO/<port>/CEC/send
ɯ
ɯ body: <command>·
Remote Control Code Sending
request-line: POST·http://<ip>/api/V1/MEDIA/VIDEO/<port>/CEC/sendUserControlClick
ɯ
ɯ body: <command>·
Audio Port Settings
Switching Audio Input
request-line: POST·http://<ip>/api/V1/MEDIA/AUDIO/XP/switch·HTTP/1.1
ɯ
body: <audio_in>:O3·
ɯ
Querying the Connected Source
request-line: GET·http://<ip>/api/V1/MEDIA/AUDIO/XP/O3/ConnectedSource·HTTP/1.1
ɯ
Querying the Connected Destinations
request-line: GET·http://<ip>/api/V1/MEDIA/AUDIO/XP/<audio_in>/
ɯ
ConnectedDestinations·HTTP/1.1
Setting Autoselect Operation Mode
request-line: POST·http://<ip>/api/V1/MEDIA/AUDIO/AUTOSELECT/O4/Policy·HTTP/1.1
ɯ
ɯ body: <op_mode>
Setting the Followed Video Port to Autoselect
request-line: POST·http://<ip>/api/V1/MEDIA/AUDIO/AUTOSELECT/O3/
ɯ
VideoFollowPort·HTTP/1.1
ɯ body: <out>
Locking the Audio Port
request-line: POST·http://<ip>/api/V1/MEDIA/AUDIO/XP/<audio_port>/Lock·HTTP/1.1
ɯ
body: <locked_state>
ɯ
Muting the Audio Port 1
request-line: POST·http://<ip>/api/V1/MEDIA/AUDIO/XP/<audio_port>/Mute·HTTP/1.1
ɯ
ɯ body: <muted_state>
MMX2 series – User's Manual
Muting the Audio Port 2
Querying the Audio Signal Presence
Analog Audio Output Volume (dB) Setting
Analog Audio Output Volume Percent Setting
Setting the Balance
Analog Audio Output Level Setting by Steps (dB)
Analog Audio Output Level Setting by Steps in Percent
Analog Audio Output Balance Setting by Steps
EDID Management
Querying the Emulated EDIDs
Querying the Validity of a Dynamic EDID
Query the Preferred Resolution of a User EDID
Emulating an EDID to an Input Port
Applied firmware package: v2.9.0b6 | LDC software: v2.7.6b4
request-line: POST·http://<ip>/api/V1/MEDIA/AUDIO/O4/Mute·HTTP/1.1
ɯ
body: <muted_state>
ɯ
request-line: GET·http://<ip>/api/V1/MEDIA/AUDIO/<audio_port>/SignalPresent·HTTP/1.1
ɯ
request-line: POST·http://<ip>/api/V1/MEDIA/AUDIO/O4/VolumedB·HTTP/1.1
ɯ
ɯ body: <level>
request-line: POST·http://<ip>/api/V1/MEDIA/AUDIO/O4/VolumePercent·HTTP/1.1
ɯ
ɯ body: <percent>
request-line: POST·http://<ip>/api/V1/MEDIA/AUDIO/O4/Balance·HTTP/1.1
ɯ
ɯ body: <level>
request-line: POST·http://<ip>/api/V1/MEDIA/AUDIO/O4/stepVolumedB·HTTP/1.1
ɯ
body: <step>
ɯ
request-line: POST·http://<ip>/api/V1/MEDIA/AUDIO/O4/stepVolumePercent·HTTP/1.1
ɯ
ɯ body: <step>
request-line: POST·http://<ip>/api/V1/MEDIA/AUDIO/O4/stepBalance·HTTP/1.1
ɯ
ɯ body: <step>
request-line: GET·http://<ip>/api/V1/EDID/EdidStatus·HTTP/1.1
ɯ
request-line: GET·http://<ip>/api/V1/EDID/D/D1/Validity·HTTP/1.1
ɯ
request-line: GET·http://<ip>/api/V1/EDID/U/<user_edid>/PreferredResolution·HTTP/1.1
ɯ
request-line: POST·http://<ip>/api/V1/EDID/switch·HTTP/1.1
ɯ
ɯ body: <source>:<destination>
