Symbol Legend
The following symbols and markings are used in the document:


WARNING! Safety-related information that is highly recommended
to read and keep in every case!


ATTENTION! Useful information for performing a successful
procedure; it is recommended to read.

Feature or function that is available with a specific
DIFFERENCE:
firmware/hardware version or product variant.


INFO: A notice, which may contain additional information. Procedure
can be successful without reading it.


DEFINITION: The short description of a feature or a function.


TIPS AND TRICKS: Ideas that you may have not known yet, but can
be useful.
Navigation Buttons
Go back to the previous page. If you clicked on a link previously,

you can go back to the source page by pressing the button.

Navigate to the Table of Contents.

Step back one page.

Step forward to the next page.
MMX2 series – User's Manual
Document Information
All presented functions refer to the indicated products. The descriptions
have been made while testing these functions in accordance with the
indicated Hardware/Firmware/Software environment:
Item
Lightware Device Controller (LDC) software
Lightware Device Updater V2 (LDU2) software
Firmware package
Hardware
Document revision: v1.11
Release date: 25-01-2024
Editor: Nikolett Keindl
Applied firmware package: v2.9.0b6 | LDC software: v2.7.6b4
About Printing
Lightware Visual Engineering supports green technologies and eco-
friendly mentality. Thus, this document is made for primarily digital
usage. If you need to print out a few pages for any reason, follow the
recommended printing settings:
Version
▪
Page size: A4
2.7.6b4
▪
Output size: Fit to page or Match page size
2.25.0b6
▪ Orientation: Landscape
2.9.0b6


TIPS AND TRICKS: Thanks to the size of the original page, a border
1.0
around the content (gray on the second picture below) makes it
possible to organize the pages better. After punching holes in the
printed pages, they can be easily placed into a ring folder.
1
Hashtag (#) Keywords in the Document
This user's manual contains keywords with hashtags (#) to help you
find the relevant information as quick as possible.
The format of the keywords is the following:
The usage of the keywords: use the Search function (Ctrl+F / Cmd+F)
of your PDF reader application, type the # (hashtag) character and the
wished keyword.
special keyword indicates a new feature/function that has
The #new
just appeared in the latest firmware or software version.
Example
#dhcp
This keyword is placed at the DHCP setting command in the LW3
Programmer's reference section.
3
2 3
#<keyword>
