0x8E—Bits[7:0] Active Pixel End MSB
See Register 0x8D.
0x8F—Bits[6:0] NDF
See Register 0x87.
0x90—Bits[7:0] Audio Infoframe Version
0x91—Bits[7:4] Audio Coding Type
These bits identify the audio coding so that the receiver may
process audio properly.
Table 36.
CT [3:0] Audio Coding
0x0 Refer to stream header
0x1 IEC60958 PCM
0x2 AC-3
0x3 MPEG1 (Layer 1 and Layer 2)
0x4 MP3 (MPEG1 Layer 3)
0x5 MPEG2 (multichannel)
0x6 AAC
0x7 DTS
0x8 ATRAC
0x91—Bits[2:0] Audio Channel Count
These bits specify how many audio channels are being sent:
www.BDTIC.com/ADI
2 channels to 8 channels.
Table 37.
CC [2:0] Channel Count
000 Refer to stream header
001 2
010 3
011 4
100 5
101 6
110 7
111 8
0x92—Bits[4:2] Sampling Frequency
0x92—Bits[1:0] Ample Size
0x93—Bits[7:0] Max Bit Rate
For compressed audio only, when this value is multiplied by
8 kHz represents the maximum bit rate. A value of 0x08 in this
field yields a maximum bit rate of (8 kHz × 8 kHz = 64 kHz).
0x94—Bits[7:0] Speaker Mapping
These bits define the mapping (suggested placement) of
speakers.
Table 38.
Abbreviation
FL
FC
FR
FCL
FCR
RL
RC
RR
RCL
RCR
LFE
Rev. 0 | Page 49 of 60
AD9380
Speaker Placement
Front left
Front center
Front right
Front center left
Front center right
Rear left
Rear center
Rear right
Rear center left
Rear center right
Low frequency effect
