AD9380
Hex Read/Write
Address or Read-Only
0x9E Read
0x9F Read
0xA0 Read
0xA1 Read
0xA2 Read
0xA3 Read
0xA4 Read
0xA5 Read
0xA6 Read
0xA7 Read
0xA8 Read
0xA9 Read
0xAA Read
0xAB Read
0xAC Read
0xAD Read
0xAE Read
0xAF Read
0xB0 Read
0xB1 Read
0xB2 Read
0xB3 Read
0xB4 Read
0xB7 Read
0xB8 Read
0xB9 Read
0xBA Read
0xBB Read
0xBC Read
0xBD Read
Default
Bits Value Register Name
[7:0] VN6
[6:0] New Data Flags
[7:0] VN7
[7:0] VN8
[7:0] Product Description
Character 1
[7:0] PD2
[7:0] PD3
[7:0] PD4
[7:0] PD5
[7:0] New Data Flags
[6:0] PD6
[7:0] PD7
[7:0] PD8
[7:0] PD9
[7:0] PD10
[7:0] PD11
[7:0] PD12
[6:0] New Data Flags
[7:0] PD13
[7:0] PD14
www.BDTIC.com/ADI
[7:0] PD15
[7:0] PD16
[7:0] Source Device
Information Code
[6:0] New Data Flags
MPEG Source Infoframe
[7:0] MPEG Source
Infoframe Version
[7:0] MB(0)
[7:0] MB[1]
[7:0] MB[2]
[7:0]
4 Field Repeat
[1:0] MPEG Frame
Description
VN6.
New data flags (see 0x87).
VN7.
VN8.
Product Description Character 1 (PD1) in 7-bit ASCII code. This is
the first character of 16 that contains the model number and a
short description.
PD2.
PD3.
PD4.
PD5.
New data flags (see Register 0x87).
PD6.
PD7.
PD8.
PD9.
PD10.
PD11.
PD12.
New data flags (see Register 0x87).
PD13.
PD14.
PD15.
PD16.
This is a code that classifies the source device.
0x00 = unknown.
0x01 = digital STB.
0x02 = DVD.
0x03 = D-VHS.
0x04 = HDD video.
0x05 = DVC.
0x06 = DSC.
0x07 = video CD.
0x08 = game.
0x09 = PC general.
New data flags (see Register 0x87).
See CEA 861B for description.
MB [0] Lower byte of MPEG bit rate: Hz. This is the lower 8 bits of
32 bits (4 bytes) that specify the MPEG bit rate in Hz.
MB [1].
MB [2].
MB [3] (upper byte).
FR—New field or repeated field.
0 = New field or picture.
1 = Repeated field.
MF [1:0]. This identifies whether frame is an I, B, or P picture.
00 = unknown.
01 = I picture.
10 = B picture.
11 = P picture.
