0x58—Bits[6:4] MCLK PLL_N
These bits control the division of the MCLK out of the PLL.
Table 24.
PLL_N [2:0] MCLK Divide Value
0 /1
1 /2
2 /3
3 /4
4 /5
5 /6
6 /7
7 /8
0x58—Bit[3] N_CTS_Disable
This bit makes it possible to prevent the N/CTS packet on the
link from writing to the N and CTS registers.
0x58—Bit[2:0] MCLK fs_N
These bits control the multiple of 128 f
Table 25.
MCLK fs_N [2:0]
0
1
2
www.BDTIC.com/ADI
3
4
5
6
7
0x59—Bit[6] MDA/MCL PU Disable
This bit disables the inter MDA/MCL pull-ups.
0x59—Bit[5] CLK Term O/R
This bit allows for overriding during power down. 0 = auto,
1 = manual.
0x59—Bit[4] Manual CLK Term
This bit allows normal clock termination or disconnects it.
0 = normal, 1 = disconnected.
0x59—Bit[2] FIFO Reset UF
This bit resets the audio FIFO if underflow is detected.
0x59—Bit[1] FIFO Reset OF
This bit resets the audio FIFO if overflow is detected.
0x59—Bit[0] MDA/MCL Three-State
This bit three-states the MDA/MCL lines to allow in-circuit
programming of the EEPROM.
used for MCLK out.
S
f Multiple
S
128
256
384
512
640
768
896
1024
Rev. 0 | Page 47 of 60
0x5A—Bit[6:0] Packet Detect
This register indicates if a data packet in specific sections has
been detected. These seven bits are updated if any specific
packet has been received since last reset or loss of clock detect.
Normal is 0x00.
Table 26.
Packet Detect Bit
0
1
2
3
4
5
6
0x5B—Bit[3] HDMI Mode
0 = DVI, 1 = HDMI.
0x5E—Bits[7:6] Channel Status Mode
0x5E—Bits[5:3] PCM Audio Data
0x5E—Bit[2] Copyright Information
0x5E—Bit[1] Linear PCM Identification
0x5E—Bit[0] Use of Channel Status Block
0x5F—Bits[7:0] Channel Status Category Code
0x60—Bits[7:4] Channel Number
0x60—Bits[3:0] Source Number
0x61—Bits[5:4] Clock Accuracy
0x61—Bits[3:0] Sampling Frequency
Table 27.
Code Frequency (kHz)
0x0 44.1
0x2 48
0x3 32
0x8 88.2
0xA 96
0xC 176.4
0xE 192
0x62—Bits[3:0] Word Length
0x7B—Bits[7:0] CTS (Cycle Time Stamp) (19:12)
These are the most significant 8 bits of a 20-bit word used in the
20-bit N term in the regeneration of the audio clock.
0x7C—Bits[7:0] CTS (11:4)
0x7D—Bits[7:4] CTS (3:0)
0x7D—Bits[3:0] N (19:16)
These are the most significant 4 bits of a 20-bit word used along
with the 20-bit CTS term to regenerate the audio clock.
0x80—Bits[AVI] Infoframe Version
AD9380
Packet Detected
AVI infoframe
Audio infoframe
SPD infoframe
MPEG source infoframe
ACP packets
ISRC1 packets
ISRC2 packets
