5.2 OPERATING PANEL
• After turning on the ceramic glass cooktop, all displays briefly light up, indicating that
the cooktop is ready for use.
• The cooktop is equipped with electronic sensors that are activated by touching the
corresponding button for at least one second.
• Each time a sensor is activated, it emits an audible signal.
• Avoid placing objects on the sensor surface, as this may generate error signals.
• It is important to always keep the sensor surface clean.
14
1. On/Off key
2. Slider control - sensor field
3. Power setting - front left cooking zone
4. Power setting - fan
5. Power setting - front right cooking zone
6. Power setting - rear left cooking zone
7. Power setting - rear right cooking zone
NOTE
Most of the keys shown here will only become visible when the hob has been
switched on.
5.3 OPERATION PRINCIPLE OF THE COOKTOP EXTRACTOR
The cooktop extractor can be operated as an exhaust air or a recirculating air version. When
operated in exhaust air mode, remove the carbon filter from the appliance, as they are not
needed.
ASPIRATION MODE
The air suctioned away is purified by the grease filter and expelled into the open air
via a duct system. The exhaust air must not be expelled into:
• a smoke or exhaust gas flue that is in operation
• a shaft used for the aeration of rooms where fireplaces are installed.
13 12 11 10
2 1
9 6 8
3 4 5
8. Cooking zone timer display
9. Timer indication
10. Minus / Plus timer keys
11. Grill key
12. Warming key
13. Lock key
14. Pause key
7
