5.0 OPERATION
5.1 SYSTEM DESCRIPTION
6A
6B
1. Downdraft hob
2. Blower
3. Air inlet flap
4. Grease filter panel
5. Carbon filter (only in recirculation mode)
6. Canalization kit
A. for recirculation mode
B. for exhaust air mode
66 | ASPIRATION HOB
8
7
12 11
7. Front right Ø 160 mm cooking zone
8. Rear right Ø 200 mm cooking zone
9. Rear left 210x191 cooking zone
10. Front left 210x191 cooking zone
11. Operating panel (touch control)
12. Fan
3
4
5
1
2
9
10
