Help Menu

Figure 5.8
Info
Table 5.7
5.4

Toolbar

The toolbar can be used to select various functions.
Help menu
Displays information about Vision Configurator.
Help menu
Selecting the Connect button establishes a connection between
the PC and the sensor.
The connection between the PC and the sensor is disconnected.
Opens a saved setting.
Saves the settings made.
Settings are read out from the sensor.
All settings made are saved on the sensor.
Reset to default settings.
Perform manual trigger.
Perform LEDs trigger
Caution: If autotrigger is activated, a line image will be issued
LED
using the "Trigger LED."
Current sensor image is loaded.
