SmartRunner Detector
Installation
Pin
1
2
3
4
5
6
7
8
18
Wire color Signal
white IN trigger
brown +UB
green Data+ RS-485 RS-485 interface: Data +
yellow Data- RS-485 RS-485 interface: Data -
gray Teach
pink Good
blue GND
red Bad
Description
Trigger input. Triggers an evaluation, if the
sensor is in continuous evaluation mode
(independent)
+ 24 V power supply
Control signal for teaching in the background
line
Output 1 is set if the height profile detected
matches the taught-in profile in terms of form
and position.
Once the teach-in process has been per-
formed, this output signals that teach-in was
successful
Ground for the + 24 V power supply
Output 2 is set if:
• No object has been detected
or
• The form detected does not match the taught-in
form
or
• The position detected is outside the tolerance.
Once the teach-in process has been per-
formed, this output signals that teach-in has
not been successful
