SmartRunner Detector

Vision Configurator Software

5 Vision Configurator Software
The sensor is commissioned and operated using the Vision Configurator software.
The Vision Configurator software makes it easy to operate the sensor with its user-friendly
interface. Standard functions include making connections to the sensor, specifying the operat-
ing parameters, saving data sets, and displaying data and error diagnostics.
Note
The following user roles are predefined with different authorizations in the Vision Configurator.
User Rights and Password
User rights
Default
User
Admin
Table 5.1
Establishing a Network Connection
To establish a network connection with the sensor, proceed as follows:
1.
Supply the sensor with power.
2.
Start the Vision Configurator software.
3.
Enter your user name and password.
Note
Additional steps for user-defined installation and installation of additional components are
described in the Vision Configurator manual. The Vision Configurator manual can be found
online at www.pepperl-fuchs.com.
22
Description
View all information
Sensor configuration
Create users at same or lower level
View all information
Sensor configuration
Create users at same or lower level
View all information
Sensor configuration
The users have different access and administration rights depending on the respective
user role.
Password
A password is not required
User
Request the admin pass-
word from Pepperl+Fuchs
