SmartRunner Detector
Vision Configurator Software
5.3.4

Image Menu

Figure 5.6
Load imagefile
Open image folder
Save image
Copy image to clipboard Loads an image file to the clipboard
Upload image to device
Show graphic
Table 5.5
5.3.5

Administration Menu

Figure 5.7
User administration
Change password
Change user
Send XML file...
Load XML file...
Create reader program-
ming code
Table 5.6
28
Image menu
Loads the image file
Opens the folder in which images are currently saved
Saves the image currently displayed on the PC
Uploads an image to the device
Switches display data sent from the sensor on and off in the
image.
Image menu
Administration menu
Opens a window that shows all currently created users at the
same authorization level or lower. New users at the same authori-
zation level or lower can also be created and deleted here. In
addition, a user password can be reset to the default password
for the relevant user level.
Changes the current user's password.
The login screen opens and a different user and/or sensor can be
selected.
Saves the XML data on a computer.
Loads XML data from a computer.
Creates a reader programming code
Administration menu
