SmartRunner Detector
Operation
6.4.2

Response Telegram

The response telegram may contain 6 to 9 bytes, depending on the content. The first byte con-
tains the address of the responding reader and status information. The X position of the reader
is transmitted in bytes 2 to 5, starting with the MSB. Depending on the controller request, infor-
mation such as speed and the Y position is transmitted in the subsequent bytes. These bytes
are omitted if a corresponding request is not sent. The last byte is used to detect faults during
the data transfer.
Status (is alive)
The status always returns 0x55 if the sensor is ready for operation.
Byte
1
Result Data
Result Data provides the measurement status and result as a response.
Byte
Byte 1 - Status
Byte 2 - Result
Byte 3 - Counter
Byte 4 - Checksum
Legend
Status
Result
Counter

Software Trigger

After sending the sequence for the software trigger, the sensor triggers an image capture. No
response telegram is generated to the command.
Teach-In
After sending the sequence for the teach-in, the sensor begins the teach-in routine. No
response telegram is generated to the command.
8 7 6
PAR R/W R.4
Parity 0 1
Bit 8 Bit 7 Bit 6
Parity 0
Parity 0
Parity 0
Parity 0
Addr
Event
WRN
No Pos.
ERR
R0
R1
R3
R4
R5
5 4 3
R.3 R.2 R.1
0 1 0
Bit 5 Bit 4 Bit 3
- Addr 1 Addr 0 Event
0 R5 R4 R3
C06 C05 C04 C03
xor xor xor xor
Device address
Event occurred, currently read as 0
Unused
Is always read as 0
System error or evaluation error
Faulty background line
Object detected
Unused
Unused
Unused
Increments for each evaluation, is restarted at
0x3F
2 1 0
R.0 A.1 A.0
1 0 1
Bit 2 Bit 1 Bit 0
WRN No Pos. ERR
R2 R1 R0
C02 C01 C00
xor xor xor
41
