Commissioning

4 Commissioning
4.1

Connecting the Sensor

The sensor is configured using the Vision Configurator software. You have the opportunity to
carry out settings on the sensor directly using the Vision Configurator software.
Aligning the Sensor
Use the image display and diagram display in the Vision Configurator software to optimally
align the sensor.
1.
Power the reader via the 24 VDC socket on the device.
2.
Use the automatic exposure time control to set an appropriate exposure value.
If exposure time control was successful, the result LED will light up green.
3.
Align the sensor so that a complete line that is as narrow as possible can be seen in the image
display.
The optimal reading distance between the sensor and the measurement object is set.
