Other two-tone sequences such as high, then low tones
indicate that the card is inserted, but the card type is un-
known.

Removing a Card

Remove PC cards from Windows for Workgroups systems
(Windows 3.11) as follows. Go to step 3 for Windows 95
systems.
To remove the card, press the PC Card Release button
1.
on the side of the slot. A double tone sounds.
Pull the card firmly out of the slot.
2.
NOTE
To save energy, press the button to disconnect the
card when it is not in use. You can leave the card in
the slot while it is disconnected for easy storage.
4-20 Using Your NEC Versa
PC Card
Release Buttons
PC cards draw power even when not in use.
Removing a PC Card
