Removing a PC Card

Follow these steps to remove a PC Card.
Double click the PC Card icon on the taskbar.
1.
Select the PC Card to remove, and select Stop.
2.
The Windows operating system alerts you if any applications are still using the
card. If all applications using the card are closed, services for that card are shut
down. You receive a message saying that it is safe to remove the card.
Press the button on the side of the PC Card in the slot.
3.

Mini PCI LAN/Modem Card

Your NEC Versa TXi system may ship with a combination Mini PCI LAN/modem card
that allows you to connect your system to a local area network, or connect to the
Internet over a standard phone line. The internal LAN is a 10/100Base-TX interface
that supports both Wake on LAN and Network Boot functions. The modem supports
V.90/K56flex™ connections.

Connecting the Mini PCI LAN

Follow these steps to take advantage of the internal Mini PCI LAN.
Locate the RJ-45 network cable that ships with your NEC Versa notebook. The
1.
cable has a LAN port connector and an RJ-45 connector.
Locate and open the LAN port jack cover on the left side of the system. Locate the
2.
LAN port.
Connect the LAN port connector to the LAN port jack.
3.
Connect the RJ-45 connector at the other end of the LAN adapter cable to an RJ-45
4.
cable.
Connect the RJ-45 cable to a local area network.
5.
Communicating with Your NEC Versa 6-5
