Figure Section 5-10 Diskette Drive Screws
4. Slide the 3 1/2-inch diskette drive out of the system chassis (see Figure Section 5-
11).
Figure Section 5-11 Diskette Drive Removal
NOTE: When reinstalling the diskette drive,
note that all power cables are keyed to fit only in
the correct position. The red edge of the diskette
drive signal cable is positioned as shown in
Figure Section 5-9.
Repair 5-9
