Illustrated Parts Breakdown - NEC POWERMATE PRO2180 - SERVICE MANUAL 1996 Service Manual

ILLUSTRATED PARTS BREAKDOWN

This subsection contains the illustrated parts breakdown (IPB) and NEC part numbers for
the PowerMate Pro2200/2180 Series computer. Table Section 5-2 lists the field-replaceable
parts for the computer. Figure Section 5-18 provides the illustrated parts breakdown.
Table Section 5-2 PowerMate Pro2200/2180 Series Field-
Item
1
2
3
4
5
6
7
8
9
10
11
12a
12b
13
14
15
16
17
____________
*This data was prepared July 1996. For an up-to-date listing of spare parts, please call FastFacts (800) 366-0476 and
order document number 42181519.
NOTE: In the U.S., call 1(800) 632-4525 to
order NEC spare parts. To order options in the
U.S., call the local NEC sales office. See Table
5-1 in Section 5 for NEC telephone numbers.
Replaceable Parts List*
Description
AC Power Cable
LED Power Cable
HDD LED Cable
Sleep Switch Cable Assembly
Reset Switch Cable Assembly
Audio Cable
Microsoft Mouse
Keyboard, Chicony
Plastic Blank Panel - 5 1/4"
Microphone
Front Bezel w/IR
PowerMate Pro2200 Logo Panel
PowerMate Pro2180 Logo Panel
Internal Power Cable and Switch
20 Watt Speaker
200 Watt Power Supply with Fan
w/o Power Switch
Side Cover
Adaptec SCSI Host Adapter
Repair
Part Number
808-857649-101A
158-052170-001
158-052169-001
158-050895-004
158-050685-031
158-050824-000
158-052115-000
158-050939-000
158-030810-000
158-052116-000
158-052129-000
158-030872-021
158-030872-043
158-050906-001
158-050979-000
158-052128-000
158-052127-002
158-052132-000A
5-15
