SPEAKERS

Systems come with a high-quality stereo 20-watt speaker set, an AC adapter, and
connecting wires. The speaker set features a volume control, power on/off switch, power
lamp, and a headphone jack. Volume is controlled from the speaker or from the sound
application software. The speaker set connects to the sound board's line out jack on the
back of the system.

MICROPHONE

The microphone that comes system allows voice and sound to be recorded into data files.
The microphone connects to the sound board's MIC jack located on the back of the system.
The microphone works in conjunction with the an audio application program.

SPECIFICATIONS

System specifications are included in Table Section 1-7.
Item
Dimensions and
Weight
Keyboard Dimensions and
Weight:
Recommended Operating
Environment
Device Slots
Expansion Slots
Table Section 1-7 Specifications
Specification
Width: 8.5 inches (215 mm)
Depth: 18.3 inches (465 mm)
Height: 14.6 inches (371 mm)
Weight: 20.5 lb. (9.32 kg) (dependent upon options)
Width: 19.0 inches (48.3 cm)
Depth: 8.4 inches (21.3 cm)
Height: 1.6 inches (4.1 cm)
Weight: 3.5 to 4.0 lb. (1.6 to 1.8 kg)
o
Temperature: 50 F to 95
Relative Humidity: 20% to 80%
Three 1.6-inch high, 5 1/4-inch, front accessible slots
One 1-inch high, 3 1/2-inch front access slot
Two 1-inch high, 3 1/2-inch internal slots
Seven slots:
three 32-bit PCI slots
-- Matrox video board installed in slot 3
-- SCSI adapter installed in slot 1 in SCSI configurations
three 8-/16-bit ISA slots
one shared 8/16-bit ISA or 32-bit PCI slot
Technical Information
o o o
F (10 C to 35 C)
1-21
