Connect the power adapter to the access point, and the power cord to an
AC power outlet.
Otherwise, the access point can derive its operating power directly from
the RJ-45 port when connected to a device that provides IEEE 802.3af
compliant Power over Ethernet (PoE).
Use ONLY the power adapter supplied with this access point.
C :
AUTION
Otherwise, the product may be damaged.
If the access point is connected to both a PoE source device and an
N :
OTE
AC power source, AC will be disabled.
Observe the Self Test – When you power on the access point, verify
1.
that the Power indicator turns on, and that the other indicators start
functioning as described under
If the red DIAG/FAIL LED does not turn off, the self test has not
completed correctly. Refer to
Connect the Ethernet Cable – The access point can be connected to
2.
a 10/100/1000 Mbps Ethernet through a network device such as a hub
or a switch. Connect your network to the RJ-45 port on the back panel
with Category 5E or better UTP Ethernet cable. When the access point
and the connected device are powered on, the Ethernet Link LED
should turn on indicating a valid network connection.
The RJ-45 port on the access point supports automatic MDI/MDI-X
N :
OTE
operation, so you can use straight-through cables for all network
connections to PCs, switches, or hubs.
Position the Antennas – Each antenna emits a radiation pattern that
3.
is toroidal (doughnut shaped), with the coverage extending most in the
direction perpendicular to the antenna. Therefore, the antennas should
be oriented so that the radio coverage pattern fills the intended
horizontal space. Also, the antennas should both be positioned along
the same axes, providing the same coverage area. For example, if the
access point is mounted on a horizontal surface, all antennas should be
positioned pointing vertically up to provide optimum coverage.
(Optional) Connect the Console Port – Connect the RJ-45 console
4.
cable (included with access point) to the RS-232 console port for
accessing the command-line interface. You can manage the access
point using the console port, the web interface, or SNMP management
software.
C
HAPTER
"LED Indicators" on page
"Troubleshooting" on page
