5.2.3

Cleaning the Focus Lens

The lens has a durable coating and won't be damaged by correct and careful cleaning. If not clean,
your laser will be less efficient and heat buildup on the oil or dust itself can damage the lens.
Cleaning Frequency: Daily, after each use
Tools Needed:
• Lens-cleaning liquid
• Lens tissue or cloth
• The focus lens repair tool (J)
• Disconnect the engraver from power before cleaning.
• Completely wipe dry the surfaces after cleaning.
• NEVER allow water to come into contact with the electronic elements.
• Be careful in all of the following steps not to directly touch the lens surface
with your hands or any dirty, oily, or abrasive surface. Use lens-safe gloves or
cloths only.
Detaching the Focus Lens
1. Move the engraving table to a distance of
approximately 4 inches (10 cm) under the
lens holder.
70
≈ 4 inches (10cm)
