Omtech SH-G1060 User Manual page 21

A Left Top Access Door
B Left Bottom Access Door
C Feet
Caster Wheels
D
E Right Top Access Door
F Right Bottom Access Door
This door provides access to the main bay for work on the mirrors and Y-axis rail.
This door provides access to the laser power supply.
These feet can be rotated down to help anchor the machine in place.
The front wheels include locks to hold the engraver in place.
This door provides access to the control panel, buttons, and sensors for maintenance
at the front rear, and sides and repair.
This door provides access to the mainboard, motor drivers, and power supplies.
