Focusing - Omtech SH-G1060 User Manual

4 Operation

4.2.4 Focusing

1. Open the cover to check that your sample material is under the laser head.
Never attempt to focus the laser without some material on the workbed.
2. Press on the control panel to enter the
following menu.
3. Click Auto focus on the screen.
4. Press on the control panel to confirm.
5. Close the cover.
Optionally, you can also focus manually
as below:
1. Open the cover to check that your
sample material is under the laser
head.
2. Place the acrylic focus tool on top
of the material and carefully raise
the workbed. The laser head should
barely touch the top of the acrylic
tool without applying any pressure,
ensuring the engraving distance is
correct.
3. Close the cover.
Keyboard Lock+
Set factory para
FST default para
Acrylic
Focus Tool
47
IP config+
Axes Reset+
Material
