A Design Display
B Parameters
C Coordinates
D Layers
E Laser Status
F Progress Bar
G Job Number
Design Dimensions
H
I Internet Status
Shows the whole file's track and the running track.
Displays the running file's fi le number, speed, max power, etc.
Displays the current coordinates of the laser head.
Displays the layer parameters of current or previewed fi les.
Parameters from left to right are layer number, color, speed, and
maximum power.
Displays the current status of the machine: Idle, Running, Paused, or
Finished. The processing time is shown on the right side.
Displays the progress of the current file.
Shows the count of completed runs of the current fi le.
Displays the dimension of the current file.
Displays the status of the machine's internet connection.
