NDW3-2500 drawout type
Dimensions
Horizontal Wiring
Vertical Wiring
Note: For the circuit breaker, X and Y are the
symmetric axes of the front cover;
Internal & confidential file
File No.:NDT2920202
第 99 页 共 149 页
Fixed Details
Rated current
630A, 800A, 1000A, 1250A
1600A, 2000A, 2500A
File Version:4
Detail
Detail
Size of busbar a
(mm)
15
20
