Auxiliary contact form
Agreed thermal current Ith
Minimum load
Breaking
capacity
4.3.2 Closing ready signal output device
Closing ready signal output device of the circuit breaker is the output signal device
that reflects the operating mechanism to achieve the closed state. It can output signals if it meets the
following mechanical states. See the table below for technical parameters.
 Circuit breaker off state;
 Energy storage in place;
 No disconnection instruction;
 Undervoltage release closing in place;
 Controller fault tripping reset.
Frame size
Breaking capacity
4.3.3 Position status signal output device of the drawer seat (on the drawer seat)
When the drawout type circuit breaker body is in the "Separation", "Test"
and "Connection" positions of the drawer seat, the triolocation electric
indication device can output the electrical status signal corresponding to the
three positions with the signal output terminal located on the left side of the
drawer seat. 3 position signal contact is in series with the drawer seat's position
locking signal contact. For shaking in or out operation, when the red button on the drawer seat pops out,
