N-pole protection, current unbalance protection, MCR making capacity protection
■ Maintenance function: With fault record (8 times), historical current peak record, contact wear
equivalent, query of operation times, clock function, self-diagnostic function, test function and fault
display function
■ With a remote reset device, realize remote recovery (optional accessories) after fault tripping of the
controller
1.5.4 Integrated communication network
The NWK22/NWK32 type controller can realize remote sensing, remote control, remote regulating and
remote communication - "four remotes" data transmission function through the communication interface (to be
used with the communication adapter and signal unit).
With the communication adapter, realize the conversion of DeviceNet and Profibus-DP protocols for data
transmission.
1.5.5 AC 1140V circuit breaker
The HU (AC1140V) type circuit breaker and XU (AC1140/1380/1500V) type circuit breaker are selected,
which can be used in the power distribution system in special fields such as metallurgy, rail transportation, pipe
gallery, energy saving and environmental protection.
1.5.6 Three-proofing circuit breaker
The TH (thermal-humidity) type circuit breaker can meet the three-proofing requirements of moisture-
proofing, mould-proofing and salt spray-proofing, and complies with JB/T834 Technical Requirements of
Tropical Type Low-voltage Apparatus while having passed the following standard related tests:
■ Thermal-humidity test: GB/T 2423.4-2008 Environmental Testing for Electric and Electronic Products.
Part 2: Test Method Test Db: Alternating Thermal-humidity (12h + 12h Cycle);
■ Mould growth test: GB/T 2423.16-2008 Environmental Testing for Electric and Electronic Products.
Part 2: Test Method Test J and Guidelines: Mould
■ Salt spray test: GB/T 2423.18-2012 Environmental Testing Part 2: Test Method Test Kb: Salt spray,
Alternating salt spray (Sodium chloride solution)
■
Enclosure protection grade: GB/T 4208-2008 Enclosure Protection Grade (IP code)
1.5.7 Convenient wiring mode
■ Upper and lower wiring of the main circuit is available;
■ Connection mode.
Wiring mode
■ Horizontal wiring
Conve
■ Vertical wiring
ntional
■ Horizontal extended wiring
Special
■ Vertical extended wiring
Internal & confidential file
文件编号:NDT2920213
NDW3-1600 NDW3-2500
√ √
√ √
√
—
√
—
第 10 页 共 149 页
NDW3-6300
4000A
NDW3-4000
6300A
5000A
√ √ —
√ √ √
√ √
—
√ √ √
文件版本:17
NDW3-7500
4000A
6300A 7500A
5000A
√ — —
√ √ —
√ —
—
√ √ √
