nader NDW3 Series Manual page 144

16 Auxiliary contact
17 Internal Accessories
18 External accessories
19 Wiring mode
20 Product usage type
21 Special notes
Rated working
22
voltage
23
Language type
Internal & confidential file
File No.:NDT2920202
A4-Four-group conversion, A6-Six-group conversion, A44-Four normally
opened and four normally closed
A4-Four-group conversion, A6-Six-group conversion
A44-Four normally opened and four normally closed,
A66 -Six normally opened and six normally closed
BX - Closing ready signal output unit
JS - Counter functional unit
CM1 - Drawout type (with the right side of the door interlock); CM2 -
Drawout type (with the left side of the door interlock)
CX - Drawer seat three-position signal output
M - Doorframe
F - Dust cover
R - Relay module
NWDF1 Power supply module
P1-DC24V
P3-AC380V/AC400V,AC220V/AC230V
P5-DC220V,DC110V
S - Button lock
BC - Programmable output module (6-channel)
IO1 - Remote I/O module C8
IO2 - Remote I/O module S12
IO3 - Remote I/O module SC64
IO4 - Remote I/O module SCM423
AM - Accessory monitoring unit
P2 - Voltage conversion module
TC - Energy-storing signal communication module component
Not marked - Horizontal wiring, J1 - Horizontal extended wiring, J3 Vertical
wiring, J4 - Vertical extended wiring
J5 - Mixed wiring (upper horizontal, lower vertical), J6 - Mixed wiring (upper
vertical, lower horizontal)
J7 - Mixed extended wiring (upper horizontal and lower vertical), J8 - Mixed
extended wiring (upper vertical and lower horizontal)
Not marked- Conventional, TH- Wet heat, FD- Windpower, Plateau
Customer's special requirements
Not-marked - AC690V and below, KV4-AC800V, KV5-AC1000V, KV6-
AC1140V， KV7-1380V，KV8-1500V
Not-marked-Chinese； Y-English；
第 144 页 共 149 页
ZY-Chinese & English
File Version:4
Applicable to NDW3-1600
Applicable to
NDW3-2500,NDW3-4000,
NDW3-6300,NDW3-7500
This shall be omitted if without
this accessory
1. Power supply module, relay
module, external current leakage
transformer, programmable output
module, message module,
communication adapter and N-pole
external transformer should be used
with the controller;
2. Carry out the sequence
arrangement according to the table,
with "/" for separation;
3. The accessory monitoring unit can't
be selected with the communication
function, signal unit and controller
with "V" and "P" functions
simultaneously;
4. The energy-storing signal
communication module component
can't be selected with the controller
with "V" and "P" functions
simultaneously.
NDW3-6300/7500 with the rated
current of 6300A only has two
wiring modes: Vertical wiring and
vertical extended wiring, with the
rated current of 7500A only has
vertical extended wiring
1,Only NWK22/32 controllers
have Chinese-English switch
function
2,Chinese and English prodcuts
use Chinese-English lables
except controller nameplate.
