nader NDW3 Series Manual page 148

Voltage-check
closing device
Auxiliary contact
Closing ready
Counter
Drawer seat door
interlock
Position indication
Door frame
Dust cover
IP54 transparent
cover
Relay module
Power Supply
Module
Safety lock
Button lock
Programmable
module
Remote I/O module
Accessory
monitoring unit
Voltage conversion
module
Energy-storing signal
communication
Interlock
ing
Off-position lock
accessor
ies
Internal & confidential file
File No.:NDT2920202
Is there any wiring harness: □ 0 (no) □ 1 (yes)
□A4-Four-group switching
NDW3-1600
□ A44-Four normally opened and four normally closed
□A4-Four-group switching
NDW3-
□ A44-Four normally opened and four normally closed
2500/4000/6300/7500
□ A66-Six normally opened and six normally closed
□ BX - Closing ready signal output unit
□ JS - Counter
□ CM1 - Right side of the door interlock
□ CX - Drawer seat three-position signal output
□ M Doorframe
□ F Dust cover
Operation method:
□ TL-left door □ TR-transparent cover right
door
Note: The order is placed separately, including the special door frame. If you choose this
accessory, the regular door frame is not selected, and the opening size of the two door frames
is different.
□ R Relay module
□P1-DC24V
□P3-AC380C/AC400V,AC220V/AC230V
□P5-DC220V,DC110V
□ A Safety lock
Note: Applicable to NDW3-2500,NDW3-4000,NDW3-6300,NDW3-7500.Select one from
safety lock and off-position key lock
□ S Button lock
□ BC Programmable output module (6-channel)
□ IO1 remote I/O module C8 □ IO2 remote I/O module S12 □ IO3 remote I/O module SC64 □ IO4
remote I/O module SCM423
Note: To be used with the optional power supply module
□ AM - Accessory monitoring unit
Note: It can't be selected with the communication function, signal unit and controller with "V" and "P"
functions simultaneously
□ P2 - Voltage conversion module
□ TC - Energy-storing signal communication module component
Note: It can't be selected with the controller with "V" and "P" functions simultaneously
Operation method:
□ Direct operation (one-hand operation,
default)
□ Manual pressure (two-hand operation)
Note: 1. All frames can be interlocked; 2. Please consult our company for other special
interlocks.
第 148 页 共 149 页
File Version:4
□ A6-Six-group switching
□ A6-Six-group switching
□ CM2 - Left side of the door interlock
Frame size:
□1: 1600A □2: 2500A and above
□ SF11-One lock one key □ SF21-Two locks one
key □ SF31-Three locks one key
□ SF32-Three locks two keys
locks three keys
□ SF53-Five
