nader NDW3 Series Manual page 3

normally closed auxiliary contact remains the original
terminal definition；
3. Add NDW2-2500/6300 frame auxiliary contact（four-
group conversion and six-group conversion） relative
contents；
4. Order specification add language type option.
1. Correct NDW3-1600 product four-open and four-closed
auxiliarycontact wiring number, changed to 47-62；
12
2. Correct temperature derating coefficient table NDW3-4000 frame
3200A and 4000A at +60℃, both changed to 3120A.
1.Add NDW3-7500 frame；
13
2.Update photos of ACB and ETU
3. Correct mistakes
1. Added 2500/6300XU series parameters;
2.1600 increase S-type breaking;
3. Delete the statement that the arc extinguishing chamber and the
contact system have multiple patents;
4. The 1600 controller power module is built-in, and the installation
14
size and secondary wiring diagram are changed;
5. The wiring bolts and the instruction manual are changed to optional
accessories;
6. All frames cancel the 20# ground wire of the secondary circuit;
7. The power of the electric operating mechanism is changed from
output power to input power;
1. Update the voltage and breaking capacity high altitude derating
table 2;
2. Added 4000 frame 3600A rated current related parameters;
3. Added 4000XU parameters
15
4. Update the minimum electrical clearance distance of copper bars;
5. Update the safety distance between the circuit breaker and the
cabinet
Remove 2000/3200 frame electric power
1. Update the relevant content of disconnected location lock
16
2. Increase the content of IP54 transparent cover
