Mixed Wiring (Upper Horizontal, Lower Vertical)
Mixed Wiring (Upper Vertical, Lower Horizontal)
Note: For the 3-pole circuit breaker, X and Y are the symmetric
axes of the front panel;
Internal & confidential file
File No.:NDT2920202
第 95 页 共 149 页
File Version:4
Detail
Detail
Rated current
200A, 400A, 630A
800A, 1000A, 1250A, 1600A
Size of busbar a
(mm)
10
15
