nader NDW3 Series Manual page 72

Mounting plate of the
circuit breaker cabinet
Model
NDW3-1600
NDW3-2500
NDW3-4000
NDW3-6300
NDW3-7500
4.6.4 Door interlock (on the drawer seat)
Installed on the right or the left side of the drawer seat. When the drawout type circuit breaker is in the
separation position.
It can avoid opening of the cubicle door.
4.7 Power Supply Conversion System
Internal & confidential file
File No.:NDT2920202
Mask centerline of the
circuit breaker
a
Fixed Drawout
type type
18
27
27
第 72 页 共 149 页
Mounting plate of the
circuit breaker cabinet
Drawout type
b
Fixed Drawout Fixed
type type type
155 187.5 91.7
204 243.7 106
204 243.7 106
File Version:4
Drawer seat off position
Drawer seat connection
position
Unit: mm
c d
Drawout Fixed Drawout
type type
108.2 26.4
143.8 26.4
104.4 26.4
type
