The IP54 transparent cover is an accessory that can be installed on the cabinet door and can increase the
protection level to IP54. The protective cover is assembled with a special door frame. If you choose this
accessory, you do not need to choose a conventional door frame. The size of the opening of the cabinet
door is different from that of the conventional door frame. For the opening size, please refer to the
opening drawing of the cabinet door. The door frame and IP54 transparent cover are assembled and
shipped. Customers can choose to open the door on the left or right, and assemble it directly on the
cabinet door according to the instructions.
a.
Dimensions of IP54 transparent cover of NDW3-1600 products
