Circuit Breaker Ordering Notes (Please Fill In Numbers In - nader NDW3 Series Manual

Circuit Breaker Ordering Notes
can be found in the Manual)
User unit
Shell frame level
Installation mode
Rated current (A)
Breaking type
Number of poles
Basic
parame
ters
Wiring mode
Product type
Controller model
Internal & confidential file
File No.:NDT2920202
(Please fill in numbers in_____, and check √ in □. Related contents
□ NDW3-1600 □ NDW3-2500
□ Fixed type □ C - Drawout type
NDW3-1600: □200 □400
NDW3-2500: □630 □800
NDW3-4000: □800 □1000 □1250 □1600 □2000
NDW3-6300: □4000 □5000 □6300
NDW3-7500: □4000 □5000 □6300 □7500
□ S-standard breaking (below AC690V) □ H-high breaking (below AC690V) □ HU-high voltage
breaking (AC800V)
□ HU-High voltage breaking (AC1000V) □ HU-High voltage breaking (AC1140V)
□ XU-Ultra High Voltage Breaking (AC1140V) □ XU-Ultra High Voltage Breaking (AC1380V) □ XU-
Ultra High Voltage Breaking (AC1500V)
Note: These options are not distinguished with NDW3-1600, no selection required.
There are not S or H breaking type with NDW3-7500.
□3 (3-pole) □4 (4-pole) □ 5 (3P+N)
□ Horizontal wiring (standard configuration)
□ J3 - Vertical wiring
NDW3-1600
□ J5 - Mixed wiring (upper horizontal and lower vertical)
□ J6 - Mixed wiring (upper vertical and lower horizontal)
□ Horizontal wiring (standard configuration) □ J1 - Horizontal extended wiring □
J3 - Vertical wiring
NDW3-2500
□ J5 - Mixed wiring (upper horizontal, lower vertical)
□ J6 - Mixed wiring (upper vertical, lower horizontal)
□ Horizontal wiring (standard configuration) □ J1 - Horizontal extended wiring
NDW3-4000
□ J3 - Vertical wiring
□ Horizontal wiring (In≤5000A standard)
□ J3- Vertical wiring (In=6300A standard)
J5 - Mixed wiring (upper horizontal, lower vertical), J6 - Mixed wiring (upper
NDW3-6300
vertical, lower horizontal)
□ J7-mixed extended wiring (upper horizontal, lower vertical)
□ J8-Mixed extended wiring (upper vertical, lower horizontal)
Note: In=6300A only Vertical wiring, Vertical extended wiring.
Horizontal wiring (In≤5000A standard)
J3- Vertical wiring (In=6300A standard)
J5 - Mixed wiring (upper horizontal, lower vertical), J6 - Mixed wiring (upper
vertical, lower horizontal)
NDW3-7500
J7-mixed extended wiring (upper horizontal, lower vertical)
J8-Mixed extended wiring (upper vertical, lower horizontal)
Note: In=6300A, only Vertical wiring, Vertical extended wiring
In=7500A, only Vertical extended wiring
Not marked - Conventional (standard)
□ KM-NWK31 (digital screen)
NDW3-1600
第 146 页 共 149 页
Number of units
ordered:
□ NDW3-4000
□630 □800 □1000 □1250
□1000 □1250 □1600 □2000
□2500
□ J4 - Vertical extended wiring
□ J4 - Vertical extended wiring
TH- hot and damp
□ KY-NWK32 (LCD)
File Version:4
Date of ordering:
□ NDW3-6300 □ NDW3-7500
□1600
□2500
□3600
□3200 □4000
□ J1-Horizontal extended wiring
□ J4-Vertical extended wiring
J1-Horizontal extended wiring
J4-Vertical extended wiring
FD- Windpower, plateau
