● Switch / button monitor
Bit Signal name
M0 Axis-1 (enabled / disabled)
Axis-1 position data increase
M1
direction
M2 Reserved
M3 Current position setting
M4 Axis-2 (enabled / disable)
Axis-2 position data increase
M5
direction
M6 Reserved
M7 Reserved
M8 Error clear (CLR)
Axis-1 current position setting
M9
command (PR1)
Axis-2 current position setting
M10
command (PR2)
M11 Reserved
M12 Reserved
M13 Reserved
M14 Reserved
M15 Reserved
Data
The status of the parameter switch located on the rear
1: ON face of the converter is monitored.
0: OFF For more details of the parameter switch, refer to
"7-2. Function and Name of Display and Setting Area".
The status of the button located on the converter panel is
1: ON (hold down) monitored.
0: OFF For more details of the button, refer to "7-2. Function and
Name of Display and Setting Area".
0: Fixed Reserved
37
Description
