8-2. Programmable Controller Setting
Set the programmable controller in order to communicate the converter and the programmable controller normally.
Note
The programming support tool manufactured by Fuji Electric Co., Ltd. is used to set the
programming controller. Refer to the programming support tool manual for how to use the tool.
(1) Connect the programmable controller to the computer which is installed the programming support tool
manufactured by the Fuji Electric Co., Ltd..
(2) Start the programming support tool, and display the screen which is set the system configuration definition.
(3) Select the E-SX bus connector connected with the converter from either "IN side terminal" or "OUT side
terminal".
(4) Display the screen which for adding a module.
(5) Check the box to "I/O terminal", and select type of the converter from the outline specification.
(6) Input the value that is set the E-SX bus address setting switch of the converter to "E-XS bus station number" .
(7) Download the system configuration definition to the programmable controller.
